The industrial liquid level switch with side mounted miniature design represents precision engineering for reliable liquid level monitoring applications. Featuring a 48mm float diameter and 1.5 inch BSP thread process connection, this switch delivers consistent performance across various tank and vessel configurations. The SPST reed switch is rated at 60 VA, with SPDT options available for more complex control requirements. With maximum switching voltage of 230 VAC/100VDC and 3 Amp switching current, this unit ensures reliable operation under demanding electrical conditions. The terminal enclosure conforms to DIN 43650 plug and socket standards, guaranteeing compatibility and safety in industrial environments while maintaining operational integrity.

This versatile level switch serves critical functions across multiple industrial sectors including manufacturing, water treatment, chemical processing, and energy production. In automotive applications, it monitors coolant and lubricant levels in machining equipment and production systems. Food processing facilities utilize it for ingredient tank monitoring while maintaining strict hygiene standards. Pharmaceutical manufacturers rely on its accuracy for precise batch processing and quality control. The construction industry employs these switches in equipment hydraulic systems, while agricultural operations use them for irrigation control and chemical tank management. Its ability to handle specific gravities down to 0.5 makes it exceptionally versatile for different liquid types and industrial requirements.

Businesses select this level switch for its proven reliability and operational efficiency in demanding environments. The maximum working pressure of 10 kg/sq.cm and temperature tolerance up to 125°C ensure long service life even under harsh industrial conditions. The switch's intelligent design minimizes maintenance requirements while maximizing operational uptime, delivering excellent return on investment. Manufacturers appreciate the consistent performance that reduces production downtime and prevents costly overflow or dry-run situations. The robust construction and quality materials ensure years of trouble-free service, making it a dependable choice for serious industrial applications where reliability cannot be compromised.

Key Features:
- 48mm float diameter for responsive and accurate level detection
- 1.5 inch BSP thread process connection for secure and reliable installation
- SPST reed switch rated 60 VA with SPDT optional configuration available
- Maximum working pressure 10 kg/sq.cm suitable for high-pressure environments
- Temperature tolerance up to 125°C for extreme condition operation

Benefits:
- Reliable performance reduces operational downtime and maintenance costs
- Versatile application across multiple industries and liquid types
- Robust construction ensures long service life in harsh conditions
- Precise level control prevents overflow and equipment damage
- Easy installation and compatibility with standard industrial systems
