The Timeline 100 represents a significant advancement in time attendance and access control technology, designed to meet the rigorous demands of modern business operations. This terminal combines a powerful 400 MHz microprocessor with 8MB flash memory and 32MB SDRAM, ensuring fast processing and reliable data handling. It utilizes the advanced Bio Bridge Vx 9.0 algorithm for efficient operation. The device features a compact design (190 x 50 x 140 mm) with a durable Acrylonitrile Butadiene Styrene (ABS) surface finish, built to withstand daily use. It supports both RFID (125kHz) and Mifare (13.56MHz) card technologies, offering reading distances of 40-80mm for RFID and 30-50mm for Mifare, with a verification time of less than one second. With storage for 10,000 cards and 30,000 transactions, it provides a robust foundation for secure and accurate attendance management.

This terminal is ideally suited for a wide range of industries that require strict access control and accurate time tracking. Manufacturing plants and industrial facilities benefit from its rugged design and ability to manage shift workers and contractor access. Corporate offices and IT parks utilize it for secure entry to premises and monitoring employee attendance. Educational institutions, from schools to universities, employ it for staff time management and controlling access to laboratories or administrative wings. Healthcare facilities find it useful for tracking staff hours and securing sensitive areas like pharmacies and record rooms. Its multi-language support for both terminal display and software (including English, Arabic, Chinese, Spanish, French, and many others) makes it a truly global solution adaptable to diverse workforce demographics.

The Timeline 100 delivers substantial business value by automating time and attendance processes, reducing administrative overhead, and minimizing errors associated with manual tracking. Its reliability is proven through a wide operating environment tolerance (0-45°C temperature, 20-80% humidity) and stable power input (DC5V 2A). The device enhances security by ensuring only authorized personnel gain access, with methods including password or card verification. Features like an external siren, work code support, greeting voice, black and white display, and short messaging capability provide additional layers of functionality and user communication. Flexible communication options, including primary TCP/IP and USB disk with optional RS232/RS485, ensure easy integration into existing network infrastructures, protecting your investment and providing a scalable solution for growing security needs.

Key Features:
- Powered by a 400 MHz microprocessor with 8MB flash and 32MB SDRAM for high-speed performance.
- Utilizes Bio Bridge Vx 9.0 algorithm and supports dual card technology: RFID (125kHz) and Mifare (13.56MHz).
- Compact and durable ABS body (190x50x140 mm) with a wide operating range of 0-45°C and 20-80% humidity.
- Ample storage capacity for 10,000 user cards and 30,000 transaction records.
- Multiple connectivity options including TCP/IP, USB disk, and optional RS232/RS485 serial communication.

Benefits:
- Streamlines payroll processing by providing accurate, automated attendance and work hour data.
- Enhances physical security through reliable access control using password or card verification.
- Reduces administrative costs and errors associated with manual timekeeping methods.
- Offers operational flexibility with support for multiple languages, work codes, and communication baud rates.
- Provides a scalable and integrable solution that fits into existing security and network systems with ease.
